Honeywell VISTA Pro Series. The hardwired workhorse.

Pick the panel that fits the building.

All three are hybrid (hardwired + wireless), expandable, and supported by AlarmNet for remote programming and over-the-air updates. We size to the property; the table below is the at-a-glance.

• VISTA-15P · up to 32 zones, 1 partition

  The smaller workhorse. 6 hardwired zones standard, expandable to 26 wireless. Up to 2 touchscreens, 32 user codes. Ideal for residential and small business — homes up to roughly 3,000 sqft, single-tenant offices, retail under 5,000 sqft.

• VISTA-20P · up to 48 zones, 2 "true" partitions

  8 hardwired zones (15 with zone doubling), expandable to 40 wireless. Up to 4 touchscreens, 48 user codes. Two truly independent partitions for in-law suites, multi-tenant, or home + business under one roof. The most-installed VISTA in the field.

• VISTA-21iP · 20P + integrated IP communicator

  Same capacity as the 20P with a built-in IP communicator on the board, plus an optional snap-in LTE radio for true dual-path. Best when you want monitoring on day one without adding a separate communicator.

• Hardwired and wireless on the same panel

  Hardwired contacts on every door, wireless on the tough-to-cable openings — both report to the same panel, the same monitoring.

• Multiple keypad form factors

  Fixed-language and alpha LCD, 7-inch color touchscreen (TUXEDOW with voice + automation), wireless keypads, and integrated keypad/transceivers — pick what fits the install location.

• Two-wire smoke compatibility

  Up to 16 two-wire smoke detectors per panel — drop-in replacement for older systems with conventional smoke wiring.

• Sprinkler & water-flow integration

  Supervisory and water-flow zones for buildings with sprinkler systems — required code in many commercial spaces.

• Up to 32 schedules

  Auto-arm at close, auto-disarm at open, holiday exceptions — handles real business hours without staff thinking about it.

• Total Connect 2.0 + AlarmNet

  Same app and monitoring portal as the wireless Pro Series. Remote programming, OTA firmware updates, mobile alerts, video viewing.

Quick answers.

• Why hardwired instead of wireless?
  Hardwired never needs sensor batteries replaced, can't be jammed by an RF attacker, and is more reliable in metal buildings (warehouses, churches with steel structure, brick-and-block commercial). For new construction we always recommend hardwired contacts — the wires get pulled before drywall and the install cost difference is small. For retrofits on a finished house, wireless usually wins on labor cost.
• Can I mix hardwired and wireless on the same panel?
• What about the panel/keypad upgrade — keep my existing devices?
• Is VISTA good for commercial?
• Does the panel work without a phone line?
